BeastWire Mesh Guarding

Wire Partitions Rack Safety Systems Tenant Storage Lockers

Advantages/Benefits

BeastWire Mesh Guarding was created to provide customers with ONE-STOP SHOPPING for Pallet Rack Safety Systems, Tenant Storage Lockers, Infill Panels, and a variety of Wire Mesh Partitions. All BeastWire systems come standard with a 10 gauge welded wire in a 2” square pattern. Optional wire types are available including a heavy-duty 6 gauge welded wire, the industry standard 10 gauge woven wire, sheet metal infill, and expanded metal (flat or standard).

The Beast, Unleashed

  • INSTANTANEOUS QUOTES!
    Using our exclusive online 3D Configurator, BeastBuilder, point and click your way to a quote along with a full set of drawings. Only at: BeastWireMesh.com
  • DURABILITY = LONGEVITY
    10ga welded wire provides lasting security and safety.
  • FASTER INSTALLS, GUARANTEED!
    With universal parts and hardware, installation is a breeze!
  • REASONABLY PRICED & READILY AVAILABLE
    Standard sized parts are kept in stock, allowing for quick-shipment (48hrs or less!)
  • VERSATILITY FOR THE FUTURE
    BeastWire systems can be custom designed to meet ANY requirement! Cages over 30’H, special doors and locks, shelves, and more!

For more information on BeastWire Mesh Guarding or the 3D Configurator, please visit www.BeastWireMesh.com

BeastWire Wire Mesh Enclosure



BeastWire Storage Lockers

Wire Partitions Technical Specifications

BeastWire Panels

Panels

Constructed standard with 10-gauge wire, welded in a 2” square pattern. Panels are welded into a 1-1/4” angle frame providing maximum security. Optional wire mesh types/patterns include a 6ga welded wire, 10ga woven wire, sheet metal, expanded metal (flat or raised), and custom matching upon request. All systems are modular and can be expanded by adding posts/doors/panels.

Hardware

Universal Hardware

All hardware kits consist of 5/16” carriage bolts and nuts.

BeastWire Universal Posts

Universal Posts

Panels are stacked vertically between 14-gauge 2” square tube posts. All posts have identical hole patterns and include a 2” x 7” base plate.

BeastWire Hinge Door

Door Options

Hinge, slide, dutch (2 halves separated by a shelf), bi-parting hinge/slide, and tunnel doors. Each is constructed of same materials as panels. Wide assortment of sizes and lock options available.

Rack Safety Systems Technical Specifications

Rack Safety Panel

Panels

Constructed of same materials as Wire Partitions panels.

Brackets

Fixed w/ Adjustable Offset (FAO) brackets consist of 3” x 1/8” steel formed at one end (upright-side). Multiple punched holes allow for varying range of offsets. Universal brackets are designed to fit uprights other than standard tear-drop pallet racking. Each brackets consists of a 2” perforated square tube and a 1-3/4” sleeve (inside) which allows users to also adjust the offset in the field as necessary.

Doors

Standard door systems are bi-parting hinge doors equipped with a padlock hasp. Sliding doors, single hinge doors, and custom sizes available upon request.

TENANT STORAGE LOCKERS Technical Specifications

Storage Locker Panels

Panels

Constructed of same materials as Wire Partitions panels.

Shelves

Same construction as panels with options for 6-gauge welded wire mesh or 16-gauge sheet steel infill.

Doors

Offered in single, double, or triple tier configurations. Single tier units are available with slide or bi-parting hinge doors. Each door comes with a padlock hasp.

Hardware

Universal Hardware

All hardware kits consist of 5/16” carriage bolts and nuts.

Finishes

All materials go through a two-stage phosphate wash with a finish of polyester powder coat in gray. Optional finishes include black, yellow, red, blue, green, and white for a nominal upcharge. Custom color matching and galvanizing available upon request.
